VM-3HDT HDMI to Long–Reach HDBaseT DA

1:3+1 4K60 4:2:0 HDMI to Long–Reach HDBaseT DA

VM−3HDT is a high−quality, long−reach 1:3 HDBaseT extender distributor that takes one HDMI input, with IR and RS−232 control signals, converts it to an HDBaseT extension line signal and distributes it to 3 HDBaseT outputs that connect to compatible HDBaseT receivers such as TP−580R. VM−3HDT distributes signals with resolutions of up to 4K@60Hz (4:2:0), and includes an HDMI LOOP output for connecting to an additional unit in a daisy chain.

QUICK FACTS

• 1:3 HDMI extender distributor
• Up to 70m (230ft) at 1080p
• Up to 40m (130ft) at 4K (4:2:0)
• Up to 4K@60Hz (4:2:0) 24bpp video resolution
• HDMI 2.0, HDCP 1.4, HDBaseT 1.0 compliance
