VP-558 Presentation Boardroom Router / Scaler System

11x4:2 Presentation Boardroom Router / Scaler System

The VP−558 is a high−performance 11x4 ProScale presentation scaler/matrix switcher that can output four independent scaled images. Each output includes an HDMI and HDBaseT connector. The product supports analog, digital and embedded audio.

VP−558 features six HDMI inputs, four HDBaseT inputs, an analog VGA input, and a 4x1 USB switcher. VP−558 also includes a microphone input, independent stereo audio outputs, a monitor output, an amplified speaker output, and audio DSP features.

QUICK FACTS

• Pix–Perfect™ Scaling Technology
• HDBaseT Range — up to 70m (230ft)
• 4x1 USB Switcher
• OSD (On Screen Display)
• Front–panel LCD — For status display
• Input/Output Audio Level Adjustment
• Selectable Microphone Talkover or Mix Modes
• Built–in Power Amplifier
• Built–in ProcAmp
• Control — RS–232, Ethernet with built–in Web pages
