VS-211HA HDMI Auto Switcher with Audio
2x1 HDMI Auto Switcher with Audio
The VS−211HA is a high−performance automatic standby switcher for HDMI video and unbalanced stereo audio signals.
The VS−211HA can be used as a manual 2x1 switcher or automatic switcher. The switcher uses a priority input or last connected input.
KEY FEATURES
- Max. Data Rate — 6.75Gbps (2.25Gbps per graphic channel).
- HDMI & HDCP Compliant.
- HDTV Compatible.
- Advanced Auto Switching — Based on video clock detection.
- Automatic Output Shutdown — If no input signal is detected after a configurable idle period.
- 3D Pass Through.
- EDID PassThru — Passes EDID signals from display to source.
- Audio Return Channel (ARC) Pass Through.
- Parallel Unbalanced Stereo Audio Switching.
- Contact Closure Remote Control — For manual switching override.
- DIP–Switches — For setting the switching mode.
