WP-789T HDBaseT wall−plate transmitter...

4K60 4:2:0 HDMI 1–Gang PoE Wall–Plate Transmitter with RS–232 & IR over Long–Reach HDBaseT

WP−789T is a high−performance, long−reach HDBaseT wall−plate transmitter for 4K@60Hz (4:2:0) HDMI 2.0 and HDCP 2.2 signals over twisted pair. It converts the HDMI input signal into an HDBaseT signal and transmits it to a compatible receiver. It extends video signals to up to 40m (130ft) over Kramer copper cables at up to 4K@60Hz (4:2:0) 24bpp video resolution and provides even further reach for lower HD video resolutions. This wall−plate is powered through PoE (Power over Ethernet) over the twisted pair cable.

QUICK FACTS

• HDBaseT 1.0 transmitter
• Powered by PoE (Power over Ethernet/HDBaseT)
• Up to 70m (230ft) at 1080p
• Up to 40m (130ft) at 4K@60 (4:2:0)
• Control extension

* DECORA® is a registered trademark of Leviton Manufacturing Co., Inc
